Parts Identification
15. Rear suspension unit (behind pannier)
16. Battery (beneath seat)
17. Fuel filler cap
18. Front brake fluid reservoir
19. Coolant pressure cap (beneath fuel
tank)
20. Horn
21. Fog light
22. Front fork
23. Rear brake pedal
24. Rear brake fluid reservoir
25. Oil filler cap/Dipstick
26. Coolant expansion tank (behind
drive belt pulley cover)
27. Silencer
28. Drive belt pulley
29. Rear indicator
15 16 17 18 19 20 22
29 28 23
27 26 25 24
21
