Triumph Thunderbird Commander User Manual

115
Maintenance and Adjustment
Release the wire retainer and remove the
bulb.
1. B u l b
2. Wire retainer
Installation of the bulb is the reverse of the
removal procedure.
Brake/Tail Light
Brake/Tail Light Replacement
Thunderbird Commander
The brake/tail light unit is a sealed,
maintenance free LED unit.
Thunderbird Horizon
1. Brake/tail light bulb
2. Bulb holder
cigv
1
2
Warning
The bulb become hot during use. Always
allow sufficient time for the bulb to cool
before handling. Avoid touching the glass
part of the bulb. If the glass is touched or
gets dirty, clean with alcohol before re-use.
cepa
1
2

Triumph Thunderbird Commander Specifications

General

Displacement	1699 cc
Bore x Stroke	107.1 mm x 94.3 mm
Compression Ratio	9.7:1
Max Torque	151 Nm @ 3550 rpm
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Brakes	Single 310mm disc, 2-piston caliper
Seat Height	700 mm
Fuel Tank Capacity	22 litres
Engine Type	Liquid-cooled, DOHC, parallel-twin
Fuel System	Electronic fuel injection
Exhaust	Chrome 2-into-1-into-2 system
Final Drive	Belt
Front Suspension	Telescopic forks
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Twin 310mm discs, 4-piston calipers
Weight	308 kg
Power	93 bhp
