116
Maintenance and Adjustment
Remove the rider’s seat (see page 47).
Disconnect the battery, negative (black) lead
first.
The brake/tail light bulb holder can be
located underneath the rear mudguard.
Rotate the bulb holder counter-clockwise to
release it from the lamp body.
To remove the bulb from the holder, gently
press inwards and twist counter-clockwise.
Installation of the bulb is the reverse of the
removal procedure.
Turn Signal Lights
Bulb Replacement
1. Screwdriver
Use a flat bladed screwdriver to carefully
remove the lens from the indicator to gain
access to the bulb for replacement.
When reconnecting the battery, connect
the positive (red) lead first.
To Next Page
