Triumph Thunderbird Commander User Manual

38
General Information
Left Handlebar Switches
1. Headlight dimmer switch
2. Turn signal switch
3. Horn button
4. Auxiliary lamp switch
Headlight Dimmer Switch
High or low beam can be selected with the
headlight dimmer switch. To select high
beam, push the switch forward. To select low
beam, push the switch rearwards. When the
high beam is turned on, the high beam
indicator light will illuminate.
Note:
• A lighting on/off switch is not
fitted to this model. The position,
rear light and license plate light all
function automatically when the
ignition is turned to the ON
position.
• The headlight will only function
when the ignition switch is turned
to the ON position and the engine
is running.
An alternative to turn on the
headlight, without the engine
running, is to pull the clutch lever
then turn the ignition switch to the
ON position. The headlight will be
on and remain on when the clutch
lever is released.
The headlight will go off while
pressing the starter button until
the engine starts.
1
2
3
4
cfce

Triumph Thunderbird Commander Specifications

General

Displacement	1699 cc
Bore x Stroke	107.1 mm x 94.3 mm
Compression Ratio	9.7:1
Max Torque	151 Nm @ 3550 rpm
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Brakes	Single 310mm disc, 2-piston caliper
Seat Height	700 mm
Fuel Tank Capacity	22 litres
Engine Type	Liquid-cooled, DOHC, parallel-twin
Fuel System	Electronic fuel injection
Exhaust	Chrome 2-into-1-into-2 system
Final Drive	Belt
Front Suspension	Telescopic forks
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Twin 310mm discs, 4-piston calipers
Weight	308 kg
Power	93 bhp
