General Information
Instruments
Speedometer
The speedometer indicates the road speed of
the motorcycle.
Odometer/Trip Meter/Clock/Range
to Empty
1. Trip meter display (trip 1 shown)
2. Odometer display
The odometer shows the total distance that
the motorcycle has travelled.
There are two trip meters. Either trip meter
shows the distance that the motorcycle has
travelled since the meter on display was last
reset to zero.
To switch between the trip meter, clock and
range to empty display modes, press and
release the scroll button (see below), located
on the right hand handlebar switch housing,
until the desired display is visible.
1. Scroll button
The display will scroll through in the order:
• Trip meter 1;
• Trip meter 2;
•Clock;
•Range to empty.
Trip Meter Reset
To reset either of the trip meters, select and
display the trip meter to be zeroed. Then
press and hold the scroll button for
4 seconds. After 4 seconds, the trip meter on
display will reset to zero.
Warning
Do not attempt to switch between
odometer and trip meter display modes or
reset the trip meter with the motorcycle in
motion as this may lead to loss of
motorcycle control and an accident.
TRIP
1
1
2
cfcc
1

Triumph Thunderbird Commander Specifications

General

Displacement	1699 cc
Bore x Stroke	107.1 mm x 94.3 mm
Compression Ratio	9.7:1
Max Torque	151 Nm @ 3550 rpm
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Brakes	Single 310mm disc, 2-piston caliper
Seat Height	700 mm
Fuel Tank Capacity	22 litres
Engine Type	Liquid-cooled, DOHC, parallel-twin
Fuel System	Electronic fuel injection
Exhaust	Chrome 2-into-1-into-2 system
Final Drive	Belt
Front Suspension	Telescopic forks
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Twin 310mm discs, 4-piston calipers
Weight	308 kg
Power	93 bhp
