47
General Information
Rider Seat Removal
1. L o c k r e l e a s e
2. Rider's seat
To remove the rider’s seat, remove the pillion
seat (see page 46).
Pull the lock release, located at the rear of the
seat, rearwards to release the seat from its
lock. Lift the seat up at the back for complete
removal from the motorcycle.
To refit the seat, engage the seat’s locating
tongue under the fuel tank. Press firmly
down to engage the center of the seat in the
seat lock. Refit the pillion seat (see page 46).
T
Windshield (if fitted)
Note:
• The windshield can be removed
without the use of tools
To Remove the Windshield
1. Upper mounting
2. Lower mounting
3. Latch
To remove the windshield, stand astride the
front wheel and firmly grip both sides of the
windshield close to the upper mounting.
Pull the windshield firmly to disengage the
upper mountings.
Then lift the windshield up to disengage the
lower mountings and completely remove
from the motorcycle.
To prevent detachment of the seat during
riding, after fitting always grasp the seat
and pull firmly upwards. If the seat is not
correctly secured it may detach from the
motorcycle. A loose or detached seat could
cause loss of motorcycle control and an
accident.
