Check. jf necessary. renew Wiper Blades
Examine each wiper blade in turn for damage WeI the glass
before operating the wipers and check the wiper blade
operation for smearing and adequate removal of dirt. Replace
any wiper blade thai is damaged or unsatisfactory In
operation
Service
position of wiper arms and blades ~ Wet the
windscreen.
Switch on ignition and wipers. Stop the wiper
assembly in a vertical position by switching off the ignition at
an appropriate moment and lift the wiper arm and blade from
the screen,
Do not switch
on the ignition until the arm is returned to its
normal position on the screen. If this is done the pantograph
arm, TR models. will jam. the motor will stall and the
appropriate fuse
will "blow' to prevent damage to the arm or
motor
Renew Driver's Wiper Blede ~ TR models
Depress the
clip and withdraw the wiper blade from the pivot
block.
Renew Passenger's Wiper Blade ~ TR models
Renew either Wiper Blade - Rover 3500
Depress the dip and withdraw the wiper blade from the arm.
Refit the
wiper blades by reversing the removal procedure
1688
MAINTENANCE AND ADJUSTMENTS
Fig. 40 TR Driver's side wiper blade removal
Fig.41 Wiper blade removal
59
