2503 Center Console • Owner’s Manual Supplement Chapter 2: Locations
Bilge Pump - Aft:
• Located in the aft bilge.
• Access is through the motor-well hatch.
Bilge Pump - Forward:
• Located in the mid bilge.
• Access is through the floor hatch in the space
aft of the head.
Freshwater Faucet (If Equipped):
• Located in the port aft cockpit, next to entry gate.
MOTOR-WELL
HATCH
FORWARD
BILGE PUMP
FAUCET
ENTRY
GATE
