2503 Center Console • Owner’s Manual Supplement Chapter 2: Locations
Steering Hydraulic Fluid Reservoir:
• Located under the dash panel.
• The filler cap is located on the steering colimn.
Macerator Switch (If Equipped):
• Located in the space aft of the
head compartment.
• Access is through the aft wall hatch in
the head.
Macerator Underwater Discharge Sea-
cock (If Equipped)
• Located in the mid bilge.
• Access is through the floor hatch in the
space aft of the head.
Marine Head Raw Water Intake Seacock
(If Equipped):
• Located in the mid bilge.
• Access is through the floor hatch in the
space aft of the head.
Raw Water Washdown Fitting
(If Equipped):
• Located in the starboard aft cockpit.
HYDRAULIC FLUID
RESERVOIR CAP
UNDERWATER
DISCHARGE
SEACOCK
RAW WATER
INTAKE
SEACOCK
MACERATOR
SWITCH
MACERATOR
WASHDOWN
FITTING
