BA 8010_3.0_EN (10/2016) 31 / 68
8 Working Table
The work pieces to be processed are put onto the working table. To
facilitate orientation, a horizontal and a vertical ruler are located on the
engraving table. The table is ferromagnetic for easier fixation of work
pieces.
9 Keypad
The Keypad contains multiple buttons and displays for controlling the
device.
See section 4.3 Keypad for further information.
10 Maintenance Panel
Has to be opened with a 10mm Allen key to maintain optics.
11 Cooling Fan
Air cooled laser tubes are equipped with cooling fans on the laser tube
or the laser tube cover.
12 Exhaust hose connector
13 Manufacturer's Label
Shows important data of the machine like serial number or
manufacturing date.
14 Laser Tube cover
All laser tubes are equipped with a cover.
15 Power Supply
Changes the main power to power types suitable for the mechanic and
electronic parts of the machine.
