Trotec Speedy 100R User Manual

BA 8010_3.0_EN (10/2016) 7 / 68
1.4 Technical Data / Device Specification
1.4.1 Technical Data Speedy 100
Mechanics
Working area
24“ x 12“/ 610 x 305 mm
Max. height of work piece
6,7 inch / 170 mm with 1,5 inch lens
6,2 inch / 157 mm with 2,0 inch lens
5,7 inch / 144 mm with 2,5 inch lens
Max. engraving speed
71 inch/sec. / 180 cm/sec. Standard
110 inch/sec / 280 cm/sec. Performance
Cutting speed
depending on material, thickness, laser power
Motor
Brushless DC servo
Encoder
Increment
Work piece table
Solid metal (Ferro-magnetic)
Max. load of work piece table
22 lbs / 10 kg
Lenses available
1,5”, 2,0” or 2,5”
Features
Standard:
Laser pointer (655nm, < 0,99mWcw), Ferro-magnetic table, 2” lens, USB connection, Interchangeable
exhaust connector, JobControl Basic software
Optional:
Electro-Optic Autofocus, Honeycomb Cutting Table, Rotary Attachment, Air Assist including
Compressor, Stand with Storage Area, Laser Power Upgrade, Performance Upgrade, JobControl
software Upgrade (Advanced, Expert), MCI Pad Production, Data import MAC
Control System
Laser power
Adjustable from 0 - 100% (typically 10-100%)
Interface Hardware
RS-232-C: Data Rate 19.200 -115.200 Baud
USB: Data Rate 460.800 Baud
Interface Software
JobControl, HPGL
Laser Equipment
Laser tube
Sealed off CO
2
Laser, maintenance free
Laser power: 12W – 60W
Wavelength
10,6µm
Cooling System
Air cooling system
12W – 60W unit air-cooled
Electricity, Power, Fuse
12W – 60W units
Single phase 230V / 50Hz or 115V / 60 Hz
Power consumption
1400W for 60W unit
Recommended fuse
10A for 12W – 60W 230V unit
10A for 12W – 30W 115V unit
15A for 40W – 60W 115V unit
