2-3/8” (60mm) BACKSET 2-3/4” (70mm) BACKSET
THEN DRILL 1” (25mm) HOLE IN CENTER DOOR OF EDGE 2” (50mm) IN DEPTH
MARK FOR 1-3/4” (45mm) DOOR
DRILL
2-1/8” (54mm)
HOLE
MARK FOR 1-3/8” (35mm) DOOR
IMPORTANT! PLACE TEMPLATE ON HIGH EDGE OF DOOR BEVEL
PLACE TOP 36” (915mm) ABOVE FLOOR
