I. INSTALLATION INSTRUCTIONS
PACKAGE CONTENTS
TOOLS REQUIRED
Tools Required for Installation on Pre-drilled Doors:
• Phillips Screwdriver
NOTE: DO NOT USE a drill.
Tools Required for Installation
on Doors That Require Drilling:
• Drill
• Tape Measure
• Pencil
• 2-1/8” (54mm) Drill Hole Saw
• 1” (25mm) Drill
• 1/16” (2mm) Drill
• Chisel
• Hammer
• Phillips Screwdriver
DO NOT RETURN TO STORE! If any parts are missing or damaged,
please call Customer Service toll free at 1-800-860-1677 (Toll Free, M-F 7am – 5pm PST)
Online installation videos can be viewed at TruBoltLocks.info
Exterior Assembly
Entry keys (2 ea.)
Mounting Plate
Interior Assembly
Deadbolt Strike Plate
Deadbolt Latch Set (Adjustable)
2-3/8” (60mm) to 2-3/4” (70mm)
Electronic lock requires (4) High Quality
AA Alkaline batteries. When all 4 batteries
are installed in the correct position, hear 2
beeps and the keypad will illuminate blue.
DO NOT TOUCH the keypad until the keypad
stops illuminating.
BATTERIES (NOT INCLUDED)
PAY CLOSE ATTENTION TO ALERTS
3/4” (19mm) Screws - 5 ea.
1” (25mm) Screw - 1 ea.
5/16” (8mm) Screws - 2 ea.
7/8” (22mm) Screws - 2 ea.
A
C
B
D
To Next Page
