TSC DA320 Series Service Manual

DA210/ DA310/ DA220/ DA320
Bar Code Printer Service Manual
25
7. Install back three sprints onto the
new printhead module.
8. Pressing both sides of new printhead module let latches into the printer inner
cover. Then lift up them, let latches into the socket.
9. Press down both tabs of
printhead fixing cover into the
printer inner cover.
10. Connect the prinhead harness,
ground cable and gap sensor
connector.
Latch
Press
Press
Latch
