TSC MH241 Series User Manual

13
LCD/LED Icon Indication:
Main Page Icon
Icon
Indication
Wi-Fi device is ready (option).
Ethernet is connected.
Bluetooth device is ready (option).
Remaining amount of ribbon(m).
Security lock.
TPH cleaning.
Enter the menu.
Calibrate the media sensor.
Enter the “Favorites” option.
Enter cursor (be marked in green) located option.
Feed button (advance one label).

TSC MH241 Series Specifications

General

Resolution	203 dpi
Max. Print Width	104 mm
Interface	Ethernet
Scanning Method	Thermal Transfer/Direct Thermal
Supported Barcode Types	1D Barcodes
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	60°C
Humidity	25-85% non-condensing
Weight	MH241/MH241T/MH241P: 15 kg MH341/MH341T/MH341P: 15 kg MH641/MH641T/MH641P: 15 kg
