TSC MH241 Series User Manual

19
3.3 Loading the Media
1. Open the meida cover.
2. Move the label roll
guard to the end of
the spindle, then turn
it down and intall the
media and use it to
make label fixed.
For 1” spindle mode
OR
For 1.5” spindle mode
Note:
The media near end sensor is movable,
which can detect the capacity of media
and remind users to change the media roll.

TSC MH241 Series Specifications

General

Resolution	203 dpi
Max. Print Width	104 mm
Interface	Ethernet
Scanning Method	Thermal Transfer/Direct Thermal
Supported Barcode Types	1D Barcodes
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	60°C
Humidity	25-85% non-condensing
Weight	MH241/MH241T/MH241P: 15 kg MH341/MH341T/MH341P: 15 kg MH641/MH641T/MH641P: 15 kg
