TSC MH241 Series User Manual

12
2.3.1 LED Indication and Keypads
LED color indication:
Color
Meaning
(Green)
Solid: Power is on and ready to be used.
Flash :System is downloading data or printer is paused.
(Amber)
System is clearing data.
(Red)
Solid - Printer head open, cutter error.
Flash - Printing error, such as paper empty, paper jam, ribbon empty, or memory error etc.
Keypads:
Keypads form
Item name
Function
Select keys
Feed, Pause, Comfirm, Cancel.
Navigational keys
Select / Navigate.

TSC MH241 Series Specifications

General

Resolution	203 dpi
Max. Print Width	104 mm
Interface	Ethernet
Scanning Method	Thermal Transfer/Direct Thermal
Supported Barcode Types	1D Barcodes
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	60°C
Humidity	25-85% non-condensing
Weight	MH241/MH241T/MH241P: 15 kg MH341/MH341T/MH341P: 15 kg MH641/MH641T/MH641P: 15 kg
