TSC MH241 Series User Manual

27
4.2 Mechanism Fine Adjustment to Avoid Ribbon Wrinkles
Ribbon wrinkle is related to the media width, thickness, print head pressure balance, ribbon film characteristics, print darkness
setting…etc. In case the ribbon wrinkle happens, please follow the instructions below to adjust the printer parts.
Ribbon Tension Adjustment Knob has 5 positions for adjustment. Use screw driver to change the ribbon tension position.

TSC MH241 Series Specifications

General

Resolution	203 dpi
Max. Print Width	104 mm
Interface	Ethernet
Scanning Method	Thermal Transfer/Direct Thermal
Supported Barcode Types	1D Barcodes
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	60°C
Humidity	25-85% non-condensing
Weight	MH241/MH241T/MH241P: 15 kg MH341/MH341T/MH341P: 15 kg MH641/MH641T/MH641P: 15 kg
