TSC MH241 Series - Loading Media in Rewinder Mode (Option-MH241 P)

23
3.6 Loading Media in Rewinder Mode (Option-MH241P)
1. Open the media
cover and load
the meida.
2. Install the label as indicated
and set printer mode to
Rewinder Mode.
3. Install the paper
core onto the
rewind spindle.
4. Feed the leading edge of liner
through the peel-off module
slot as indicated.
5. Spin the rewind
spindle
conterwise to
maked the media
be fixed.
6. Adjust the media rewind guide
to fit the label width.Close print
head and the lower cover.
