TSC MH241 Series User Manual

20
3. Release the lever and
thread the label through
the media guide bar,
damper, media sensor,
and label guide to install
the media.
4. Adjust the lable
guide to make the
media position
fixed.
5. Adjust the sensor the
sensor to make sure the
media can be detected.
6. Close the print
head .
Black mark
sensor
(shown as ↓)
Gap sensor
(shown as▽)

TSC MH241 Series Specifications

General

Resolution	203 dpi
Max. Print Width	104 mm
Interface	Ethernet
Scanning Method	Thermal Transfer/Direct Thermal
Supported Barcode Types	1D Barcodes
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	60°C
Humidity	25-85% non-condensing
Weight	MH241/MH241T/MH241P: 15 kg MH341/MH341T/MH341P: 15 kg MH641/MH641T/MH641P: 15 kg
