TSC MH241 Series User Manual

45
Note: If printing from enclosed software/driver, the software/driver will send out the commands, which will overwrite the settings set from the
panel.
Item
Description
Default
Speed
Set the print speed. Setting range: 2~14 for 203dpi; 2~12 for 300dpi; 1~6 for 600dpi
203 dpi: 6
300 dpi: 4
600 dpi: 3
Slew Speed
Set feed speed
203 dpi: 6
300 dpi: 4
600 dpi: 3
Back Speed
Set back speed
2
Density
Set printing darkness. Setting range: 0 to 15, and the step is 1.
8
Direction
Set the printout direction. Setting Value: 0 and 1.
Direction 0: Direction 1:
0
Print mode
Set the print mode. There are 6 modes in total:
None: Next label top of form is aligned to the print head burn line location. (Tear Off Mode)
Batch Mode: Once finishing the printing process, label will be fed to the tear plate location.
Peeler Mode: Enable the label peel off mode.
Cutter Mode: Enable the label cutter mode.
Cutter Batch: Cut the label once at the end of the printing job.
Rewinder Mode: Enable the label rewinder mode.
Applicator: The printer prints a label when it receives a signal from the applicator.
Batch Mode
Offset
Adjust media stop location. Available value setting range: -999 dots to 999 dots.
0 dot
Shift X
Adjust print position. Available value setting range: -999 dots to 999 dots.
0 dot
Shift Y
0 dot
Reference X
Set the origin of printer coordinate system horizontally and vertically. Available setting range: 0 dot to 999
dots.
0 dot
Reference Y
0 dot
Code page
Set the code page of international character set.
950
Country
Set the country code. Available setting value range: 1 to 358.
001

TSC MH241 Series Specifications

General

Resolution	203 dpi
Max. Print Width	104 mm
Interface	Ethernet
Scanning Method	Thermal Transfer/Direct Thermal
Supported Barcode Types	1D Barcodes
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	60°C
Humidity	25-85% non-condensing
Weight	MH241/MH241T/MH241P: 15 kg MH341/MH341T/MH341P: 15 kg MH641/MH641T/MH641P: 15 kg
