TSC MH241 Series User Manual

48
Delimiter Char
Set delimiter character.
N/A
Media Power Up
Set the action of the media when turning on the printer.
Feed: Printer will advance one label.
Calibration: Printer will make calibration.
Length: Printer determine length and feed label.
No Motion: Printer will not move media.
No Motion
Head Close
Set the action of the media when closing the print head.
Feed: Printer will advance one label.
Calibration: Printer will make calibration.
Length: Printer determine length and feed label.
No Motion: Printer will not move media.
No Motion
Label Top
Adjust print position vertically on the label. Value range: -120 to +120 dots.
0
Left Position
Adjust print position horizontally on the label. Value range:-9999 to +9999 dots.
0
Reprint Mode
Reprint the last label by pressing button on printer’s control panel.
Disabled
Format Convert
Select the bitmap scaling factor. The first number is the original dots per inch (dpi) value; the
second the dpi which you would like to scale.
None
Note: printing from other software/drive will overwrite the settings set from the panel.

TSC MH241 Series Specifications

General

Resolution	203 dpi
Max. Print Width	104 mm
Interface	Ethernet
Scanning Method	Thermal Transfer/Direct Thermal
Supported Barcode Types	1D Barcodes
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	60°C
Humidity	25-85% non-condensing
Weight	MH241/MH241T/MH241P: 15 kg MH341/MH341T/MH341P: 15 kg MH641/MH641T/MH641P: 15 kg
