- 23 -
3.3 Removing the Used Ribbon
1. Lift the handle to open the printer
right side cover.
2. Push the print head release lever to
open the print head mechanism.
3. Break the ribbon between the ribbon
guide bar and the ribbon rewind
spindle.
4. Push the ribbon release button and
slide the ribbon off from the ribbon
rewind spindle.
To Next Page
