Page #7 background image
2
1.1 Product Specification
1.1.1 Product standard feature
ML240
ML340
ML240P
ML340P
203 dots/inch
(8 dots/mm)
300 dots/inch
(12 dots/mm)
203 dots/inch
(8 dots/mm)
300 dots/inch
(12 dots/mm)
Thermal transfer & direct thermal
High quality die-cast aluminum design
2 operation buttons (Pause and Feed)
3 colors LED for notification light bar
2 operation buttons (The meaning of the buttons will vary
depend on the UI footer.)
4 navigational keys
3 colors LED for notification light bar
32-bit RISC high performance processor
8MB Flash memory
16MB DRAM
128MB Flash memory
64MB DRAM
USB 2.0 (High speed mode)
USB 2.0 (High speed mode)
Internal Ethernet (10/100 Mbps)
RS-232 (Max. 115,200 bps)
USB host: barcode scanner, PC keyboard, and USB
storage device
Gap transmissive sensor (Position adjustable, 5mm
88mm)
Black mark reflective sensor (Position adjustable,
0mm 81.7mm)
Gap transmissive sensor (Position adjustable, 5mm
88mm)
Black mark reflective sensor (Position adjustable, 0mm
81.7mm)

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TSC PRINTRONIX ML240P and is the answer not in the manual?

TSC PRINTRONIX ML240P Specifications

General IconGeneral
Print TechnologyThermal Transfer/Direct Thermal
Print Resolution203 dpi
Max Print Width4.09 inches
Max Print Speed6 ips
ConnectivitySerial RS-232
Label Width0.5 to 4.33 inches (12.7 to 110 mm)
Label Thickness0.003 to 0.01 inches
Power Supply100-240V AC, 50-60Hz
