TSC PRINTRONIX ML240P User Manual

10
2.2.2 Interior View
1. Ribbon rewind spindle
2. Print head pressure position adjustment knob
3. Print head release lever
4. Ribbon supply spindle
5. Label roll guard
6. Label supply spindle
7. External label entrance chute
8. Damper
9. Print head
10. Platen roller
11. Label guide
12. Black mark sensor (shown as↓)
13. Gap sensor (shown as ▽)
9
10
11
7
5
1
2
3
4
6
8
13
12
ML240/ML240P Series

TSC PRINTRONIX ML240P Specifications

General

Print Technology	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Speed	6 ips
Connectivity	Serial RS-232
Label Width	0.5 to 4.33 inches (12.7 to 110 mm)
Label Thickness	0.003 to 0.01 inches
Power Supply	100-240V AC, 50-60Hz
