TSC PRINTRONIX ML240P User Manual

12
2.3 Front Panel Control
2.3.1 LED Indication and Keypads
LED color indication:
Color
Meaning
(Green)
Solid: Power is on and ready to be used.
Flash :System is downloading data or printer is paused.
(Amber)
System is clearing data.
(Red)
Solid - Printer head open, cutter error.
Flash - Printing error, such as paper empty, paper jam, ribbon empty, or memory error etc.
Keypads (ML240 Series):
Keypads form
Item name
Function
Pause Key
Pause/ Resume the printing process.
Feed Key
Advance one label.

TSC PRINTRONIX ML240P Specifications

General

Print Technology	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Speed	6 ips
Connectivity	Serial RS-232
Label Width	0.5 to 4.33 inches (12.7 to 110 mm)
Label Thickness	0.003 to 0.01 inches
Power Supply	100-240V AC, 50-60Hz
