TSC PRINTRONIX ML240P User Manual

6
1.2 Printer Specifications
Model
ML240
ML340
ML240P
ML340P
Physical dimensions
248 (W) x 245 (H) x 330 (D) mm
Weight
7.4 kg
7.6 kg
Power
Auto sensing power supply (20% print ratio)
 Input: AC 100-240V, 1.5A, 50/ 60Hz
 Output: 60W
Environmental condition
 Operation: 5˚C ~ 40˚C (41 ~ 104˚F),
25%~85% non-condensing
 Operation: 0˚C ~ 40˚C (32 ~ 104˚F), 25%~85%
non-condensing
 Storage: -40˚C ~ 60˚C (-40 ~ 140˚F), 10%~90% non-condensing
Environmental
concern
Comply with Energy Star 2.0, REACH, RoHS, and WEEE
1.3 Print Specifications
Print Specifications
203 dpi models
300 dpi models
Print head resolution
(dots per inch/mm)
203 dots/inch
(8 dots/mm)
300 dots/inch
(12 dots/mm)
Printing method
Thermal transfer and direct thermal
Dot size
(width x length)
0.125 x 0.125 mm
(1 mm = 8 dots)
0.084 x 0.084 mm
(1 mm = 12 dots)
Print speed
(inches per second)
1, 2, 3,…6 ips
Up to 6 ips
1, 2, 3,…5 ips
Up to 5 ips
Max. print width
108 mm (4.25”)
105.7 mm (4.16”)
Max. print length
ML240: 110” (2,794 mm)
ML240P: 1000” (25,400 mm)
ML340: 40” (1,016 mm)
ML340P: 450” (11,430 mm)
Printout bias
Vertical: Max. 1 mm.
Horizontal: Max. 1 mm

TSC PRINTRONIX ML240P Specifications

General

Print Technology	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Speed	6 ips
Connectivity	Serial RS-232
Label Width	0.5 to 4.33 inches (12.7 to 110 mm)
Label Thickness	0.003 to 0.01 inches
Power Supply	100-240V AC, 50-60Hz
