TSC PRINTRONIX ML240P User Manual

21
3.5 Loading Media in Peel-off Mode (Option for ML240P Series)
1. Open the media cover
2. Load the meida and use front
panel to make calibration,
setting print mode to Peeler
Mode.
3. Open print head release
and peel-off module, pull
approximately 650 mm of
the label and remove
several labels.
4. Feed the leading edge of liner
through the peel-off module
slot.
5. Close print head, peel-off
module, and the media
cover. Press FEED button
to test the function.

TSC PRINTRONIX ML240P Specifications

General

Print Technology	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Speed	6 ips
Connectivity	Serial RS-232
Label Width	0.5 to 4.33 inches (12.7 to 110 mm)
Label Thickness	0.003 to 0.01 inches
Power Supply	100-240V AC, 50-60Hz
