TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
Main board for TE210/TE310 Series
Connector
Description
Remark
1
Power switch connector
SW1
2
Power supply (24V DC) connector
DCIN1
3
USB Device connector
USB1
4
USB Host connector
USB2
5
RS-232C connector
RS1
6
Ethernet connector
LAN1
7
RTC battery connector
BT1
1
2
4
5
7
8
9
12
10
11
14
16
15
17
18
19
20
21
13
3
6
