TSC TTP-2410MU Series

- 33 -
4. Adjustment Knob
4.1 Print Head Pressure Adjustment knob
The print head pressure adjustment knob has 5 levels of adjustment. Because the printer’s paper
alignment is to the left side of mechanism, different media widths require different pressure to print
correctly. Therefore it may require to adjust the pressure knob to get your best print quality. For
example, if the label width is 4”, adjust both print head pressure adjustment knobs to the same level. If
the label is less than 2” wide, increase the left side print head pressure by rotating the adjustment knob
clockwise and decrease the right side pressure by rotating the adjustment knob counter-clockwise to
level 1.
