TSC TTP-2610MT Series Service Manual

39
25. Plug the peel-off mini DIN cable connector into the peel-off connector and place
the cable in the cable cavity. The triangle mark on the connector must be at the
upper side.
26. Fasten 2 screws at the peel-off module to fix the peel-off module to the printer
mechanism.
