TSC TTP-2610MT Series Service Manual

38
22. Connect the DC motor harness and the DC motor control board harness to main
board. Then, reassemble the parts in the reverse procedures.
23. Loosen 4 screws to remove lower front panel and platen holder.
24. Use 2 screws to install the new platen holder (No.13) as indicated.
