TSC TTP-345 User Manual

42
Gap/Black Mark
Sensor Calibratio,
Label Length
Measurement,
Self Test and enter
Dump Mode
1.Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED becomes amber and
blinking. (Any amber will do during the 5 blinks).
 The LED color will be changed as following order.
Amber Æ red (5 blinks) Æ amber (5 blinks) Æ
green (5 blinks) Æ green/amber (5 blinks) Æ
red/amber (5 blinks) Æ solid green
 It calibrates the sensor and measures the label
length and prints internal settings then enter the
dump mode.
Note:
Please select gap or black mark sensor by GAP or BLINE
command prior to calibrate the sensor.
For more information about GAP and BLINE command,
please refer to TSPL2 programming manual.
Printer
Initialization
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED turns green after 5 amber
blinks. (Any green will do during the 5 blinks).
 The LED color will be changed as following:
Amber Æ red (5 blinks) Æ amber (5 blinks) Æ green
(5 blinks) Æ green/amber (5 blinks) Æ red/amber (5
blinks) Æ solid green
Note:
Always do gap/black mark sensor calibration after printer
initialization.
Set Black Mark
Sensor as Media
Sensor and
Calibrate the Black
Mark Sensor
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED turns green/amber after 5
green blinks. (Any green/amber will do during the 5 blinks).
 The LED color will be changed as following:
Amber Æ red (5 blinks) Æ amber (5 blinks) Æ green
(5 blinks) Æ green/amber (5 blinks) Æ red/amber
(5 blinks) Æ solid green

TSC TTP-345 Specifications

General

Print Method	Thermal Transfer
Resolution	300 dpi
Max Print Speed	5 ips
Max Print Length	90" (2286 mm)
Memory	8 MB Flash
Interface	USB 2.0, RS-232
Power Supply	External universal switching power supply
