1: Introduction 9
Figure 7. High Flow Module
(arrow on module indicates positive flow direction)
Figure 8. Low Flow Module
High Pressure
(150 PSIG, 10 bar)
Low Pressure (150 cmH
2
O
differential)
Use “+” port for airway
pressure.
Coiled Cable Connector
TTL Trigger Input
Oxygen Sensor
Connector
Coiled Cable Connector
