50 Certifier
®
FA Plus Test System
As Formatted By spreadsheet application:
Filename:
\NV1FLASH\EXAMPLE.csv
Comments:
Custom comments here
Configuration:
*Current Configuration
Module A
Model:
4081
Module A SN:
40810705010
Trigger Type:
Flow Rate
Start Trigger:
Auto
End Trigger:
Auto
Module A
Conditions:
STP
Module A Gas:
AIR
Data Section:
Module A
Module A
Module A
Flow Rate
Low
Pressure
PEEP
Pressure
Date
Time
L/Min
cmH2O
cmH2O
27/12/2007
12:03:20
-19.2
-0.256
0
Notes:
 When Continuous logging is used, each additional reading is given on a separate,
appended text line.
 Parameter value columns are formatted in the same order that they have been
configured on the display screen.
Parameter Screen Waveform Logging Data Format
Waveform Logging collects a 15-second snapshot of “raw” data from the connected
flow module. An example of the data collected in waveform logging is shown below.
