TSI Instruments Aerotrak 9303 Service Manual

1-1
CHAPTER 1
Introduction
This manual contains the cleaning, troubleshooting and repair procedures
for AeroTrak
®
Handheld 9303 and Remote Airborne Particle Counters.
N O T I C E
All calibration process steps for As Found Verification and As Left
Calibration using the TSI
®
S9900 Calibration System have been moved
to the following Service Manual:
AEROTRAK
HANDHELD AND REMOTE
AIRBORNE PARTICLE COUNTERS
MODELS 9303, 7201/7301/7310/7501/7510, 7301-p
_______________________________
SERVICE MANUAL – CALIBRATION
The AeroTrak
®
Model 9303 Handheld Airborne Particle Counter (particle
counter) is a lightweight, handheld device with a backlit LCD display. It
operates on the included lithium-ion battery or AC power. This model has
a 0.1 CFM (2.83 L/min) flow rate and counts in user-adjustable bin sizes
of 0.3, 0.5/1.0/2.0/2.5, and 5 microns (center channel is selectable). Refer
to the Model 9303 Operation Manual (P/N 6002277) for device operation.
The AeroTrak
®
Models 7201/7301/7310/7501/7510 Remote Airborne
Particle Counters (particle counter) are compact sensors. They have no
display (other than several LED indicators) and no pump (central vacuum
is used along with an integral critical orifice). Refer to the AeroTrak
Remote Airborne Particle Counters, Models 7201/7301/7501/7310/7510
Operation and Service Manual (P/N 6002276) for device operation.
Refer to the Model 7301-P Operation Manual (P/N 6004433) for device
operation.

TSI Instruments Aerotrak 9303 Specifications

General

Size Range .	0.3 to 25 µm
Channel Sizes .	0.3 µm and 5.0 µm fixed; 0.5, 1.0, 2.0, or 2.5 µm selectable middle channel.
Counting Efficiency .	50% at 0.3 µm; 100% for particles > 0.45 µm (per ISO 21501-4 and JIS)
Concentration Limits .	2, 000, 000 particles/ft3 at 5% coincidence loss
Zero Count Level .	<1 count / 5 minutes (per ISO 21501-4 and JIS B9921)
Flow Rate .	0.1 CFM (2.83 L/min)
Calibration .	NIST traceable with TSI® calibration system
Sampling Modes .	Manual and automatic
Sampling Time .	1 second to 99 minutes 59 seconds
Sampling Frequency .	1 to 999 cycles or continuous
Light Source .	Long life laser diode
Sample Probe/Tubing .	Isokinetic sampling probe
Exhaust .	Internal HEPA filter
Vacuum Source .	Internal pump
External Surface .	High impact injection molded plastic
Communication Mode .	USB serial output
Data Storage .	1, 500 sample records
Status Indicators .	Low battery and service
Display .	3.2-in. (8.1 cm) 160 x 160 monochrome LCD
AC Power . (power to AC adapter)	110 to 240 VAC 50-60 Hz Universal in-line power supply with country specific plugs
DC Power . (power to instrument)	9 VDC @ 1.5 A
Battery .	Rechargeable Li-Ion
Battery Life .	Up to 4.5 hours of continuous use
Recharge Time .	< 3 hours

Weight and Dimensions

Dimensions (L x W x H)	9.1 x 6.3 x 2.4 in. (23 x 11 x 6.2 cm) (without isokinetic inlet)
Weight .	1.3 lbs (0.58 kg) with battery
