3-1
CHAPTER 3
General Maintenance–
Models 7201, 7301, 7310,
7501, 7510
This section explains how to disassemble the units for general
maintenance and/or repair. Remove unit power to prevent damage to the
unit components.
Model
Range μm
Bin size μm
Flow Rate
CFM (L/min)
7201-01F
0.2 to 10
0.2, 0.3
0.1 (2.83)
7201-02F
0.2 to 10
0.2, 0.3, 0.5, 1
0.1 (2.83)
7201-03F
0.2 to 10
0.2, 0.5
0.1 (2.83)
7201-04F
0.2 to 10
0.2, 0.3, 0.5, 2
0.1 (2.83)
7301-01, -01F
0.3 to 25
0.3, 0.5
0.1 (2.83)
7301-02, -02F
0.3 to 25
0.3, 0.5, 1, 5
0.1 (2.83)
7501-01, -01F
0.5 to 25
0.5, 5
0.1 (2.83)
7501-02, 7501-02F
0.5 to 25
0.5, 1, 2, 5
0.1 (2.83)
7310-01F
0.3 to 25
0.3, 0.5
1 (28.3)
7310-02F
0.3 to 25
0.3, 0.5, 0.7, 1
1 (28.3)
7310-03F
0.3 to 25
0.3, 0.5, 1, 5
1 (28.3)
7510-01, -01F
0.5 to 25
0.5, 5
1 (28.3)
7510-02, -02F
0.5 to 25
0.5, 0.7, 1, 5
1 (28.3)
