94 Appendix B
Variable Name
Variable
Address
Read/Write
Integer DDC system receives
Exhaust Air Control
Minimum Position
45
Read/Write
0% to 100% Open
Exhaust Air Control
Maximum Position
46
Read/Write
0% to 100% Open
Anteroom Mode
47
Read/Write
1
2
3
6
Positive
Negative
No Isolation
Anteroom not configured
Anteroom Low
Alarm Enable
48
Read/Write
1
2
Disabled
Enabled
Anteroom High
Alarm Enable
49
Read/Write
1
2
Disabled
Enabled
Anteroom Negative
Low Alarm Setpoint
50
Read/Write
Displayed in in. W.C.
Host DDC system must divide value by
10,000 to report pressure correctly
Anteroom Negative
High Alarm Setpoint
51
Read/Write
Displayed in in. W.C.
Host DDC system must divide value by
10,000 to report pressure correctly
Anteroom Positive
Low Alarm Setpoint
52
Read/Write
Displayed in in. W.C.
Host DDC system must divide value by
10,000 to report pressure correctly
Anteroom Positive
High Alarm Setpoint
53
Read/Write
Displayed in in. W.C.
Host DDC system must divide value by
10,000 to report pressure correctly
Alarm Reset
61
Read/Write
1
2
Latched
Unlatched
Audible Alarm
Enable
62
Read/Write
1
2
On
Off
Alarm Delay
63
Read/Write
Displayed in seconds
Mute Timeout
64
Read/Write
Displayed in minutes
Door Delay
65
Read/Write
Displayed in seconds
Modbus Address
66
Read
Output 1 Signal
Type
67
Read
1
2
None
Exhaust Control
Output 1 Value
70
Read
0 to 100%
Output 2 Signal
Type
71
Read
1
2
3
4
None
Room 1 Pressure Output
Room 1 Supply Control
Room 1 Exhaust Flow Output
Output 2 Range
72
Read
If Pressure: Displayed in in. W.C.
Host DDC system must divide value by
100 to report pressure correctly
If Flow: Displayed in CFM
If Control: Displayed in % Open
Output 2 Signal
73
Read
1
2
4-20 mA
0 to10 VDC
Output 2 Value
74
Read
0 to 100%
