TSI Instruments PRESSURA RPC30

Wiring Information 121
NOTE
A 120Ω resistor should be installed on both ends of the RS-485 loop.
Figure 40. Optional Modbus and BACnet MS/TP
Communications Wiring to Model RPC30
Figure 41. Optional LONworks Communications Wiring to Model RPC30
