Appendix A
88
Outputs–Three (3)Total
Output 1 .....................................
Exhaust Control (0 to 10 VDC)
Output 2 .....................................
Supply Control (0 to 10 VDC)
Room 1 Pressure Out, Exhaust Flow Out
(0 to 10 VDC / 4-20 mA)
Output 3 .....................................
Temperature Control (0 to 10 VDC / 4-20 mA
Anteroom Pressure Out, Exhaust Flow Out, Supply Flow Out
(0 to 10 VDC / 4-20 mA)
Alarm Contacts ..........................
Relay1: Low Alarm
Relay 2: High Alarm or Room Mode
SPST, 60 W max
2A @ 30 VDC Nominal
Contacts field-configurable to open or close in alarm
condition.
Contacts close on loss of power.
TSI Through-the-Wall Sensor
Temperature Compensation
Range ........................................
55 to 95°F
Power Dissipation ......................
0.16 watts at 0 in. W.C.,
0.20 watts at 0.00088 in. W.C.
Dimensions (D x H)....................
5.58 in. x 3.34 in. x 1.94 in.
(84.8 x 141.7 x 49.3 mm)
Weight ........................................
0.2 lb.
Damper/Actuator
Types of Actuator.......................
Electric
Input Power ................................
Electric: 24 VAC, 50 VA max
Time for 90° Rotation .................
1.5 sec.
*Specifications are subject to change without notice.
