Technical Section
43
Interface Menu
MENU ITEM
SOFTWARE
NAME
ITEM DESCRIPTION
ITEM RANGE
DEFAULT
VALUE
Analog Output Full
Scale
AO2 Sig
Rnge
The AO2 Sig Rnge item selects the full scale range that
the analog output signal will represent. If the room pressure
sensor is set to:
AO2 SIGNAL TYPE
(SENSOR)
0 V / 4 mA
10 V / 20 mA
ROOM 1
PRESSURE (TSI)
- AO2 Sig Rnge
+ AO2 Sig Rnge
ROOM 1
PRESSURE
(PRESSURE
TRANSDUCER;
SENSOR MIN=0)
0
AO2 Sig Rnge
ROOM 1
PRESSURE
(PRESSURE
TRANSDUCER;
SENSOR MIN≠0)
- AO2 Sig Rnge
+ AO2 Sig Rnge
EXHAUST FLOW
0
AO2 Sig Rnge
PRESSURE:
-1.00 in. W.C.
to
+1.00 in. W.C.
FLOW: 0 to
30,000 CFM
PRESSURE:
0.10 in. W.C.
FLOW:
1000 CFM
NOTE: If Cntrl Device is set to
EXHAUST/SUPPLY/TEMP, the AO2 Sig Rnge
item will not be accessible.
Do not set AO2 Sig Rnge to a value greater than
the sensor input.
Analog Output
Signal Type
AO3 Sig
Type
The AO3 Sig Type item selects the measurement that the
analog output signal will represent.
Anteroom Pressure
Supply Flow
Exhaust Flow
Temp Control
None
Anteroom
Pressure
NOTE: Changing the AO3 Sig Type item when
Ctrl Device is set to EXHAUST/SUPPLY/TEMP
may result in loss of room or temperature control.
