TSI Instruments PRESSURA RPC30 User Manual

52
Part Two
Input2 Config Menu
Temp Setpnt
MENU ITEM
SOFTWARE
NAME
ITEM DESCRIPTION
ITEM RANGE
DEFAULT
VALUE
Set Minimum
Temperature
Adjustment
Sensor Min
The Sensor Min item is used to set the minimum reading
of the thermostat. For example, if the temperature
adjustment of the thermostat is from -5° to +5°, the
Sensor Min should be set to -5.
-10°F to 0°F
-5°F
Set Maximum
Temperature
Adjustment
Sensor Max
The Sensor Max item is used to set the maximum reading
of the thermostat. For example, if the temperature
adjustment of the thermostat is from -5° to +5°, the
Sensor Max should be set to 5.
0°F to 10°F
5°F
Set Minimum
Sensor Voltage
Output
Signal Min
The Signal Min item is used to set the minimum output
signal from the thermostat setpoint adjustment.
0 to 10 V
0 V
Set Maximum
Sensor Voltage
Output
Signal Max
The Signal Max item is used to set the maximum output
signal from the thermostat setpoint adjustment.
1 to 10 V
10 V
Reset Calibration
Reset Cal
The Reset Cal item is used to return to the factory default
calibration, undoing any field calibration adjustments. When
this menu item is entered, the controller will prompt the
user to verify that they want to do this by displaying the
message “Are You Sure.” Entering YES resets the
Sensor Min, Sensor Max, Signal Min and Signal Max
factors for this sensor to defaults. Entering NO will cancel
the reset.
None
N/A
