TSI Instruments PRESSURA RPC30 User Manual

Technical Section
63
Input7 Config Menu
Exh Pres Flow
MENU ITEM
SOFTWARE
NAME
ITEM DESCRIPTION
ITEM RANGE
DEFAULT
VALUE
Set Maximum
Sensor Pressure
Output
Sensor Max
The Sensor Max item is used to set the maximum reading
of a flow station and pressure transducer used to measure
exhaust air flow. For example, if the pressure transducer
has a range of 0 in. W.C. to +0.25 in. W.C. 0 to +62.5 Pa),
the Sensor Max should be set to +0.25 in. W.C.
(+62.5 Pa).
0 to + 1.00 in. W.C.
1.00 in. W.C.
Set Minimum
Sensor Voltage
Output
Signal Min
The Signal Min item is used to set the minimum output
signal when a flow station and pressure transducer is used
to measure exhaust flow
0 to 10 V
0 V
Set Maximum
Sensor Voltage
Output
Signal Max
The Signal Max item is used to set the maximum output
signal when a flow station and pressure transducer is used
to measure exhaust flow.
1 to 10 V
10 V
Flow Station Low
Calibration
Low Cal
The Low Cal menu item enters the LOW CAL Submenu.
See Flow Calibration
Flow Station High
Calibration
High Cal
The High Cal menu item enters the HI CAL Submenu.
See Flow Calibration
Reset Calibration
Reset Cal
The Reset Cal item is used to return to the factory default
calibration, undoing any field calibration adjustments.
When this menu item is entered, the controller will prompt
the user to verify that they want to do this by displaying the
message “Are You Sure.” Entering YES resets the Low
Cal, High Cal and K-Factor factors for this sensor to
defaults. Entering NO will cancel the reset.
None
N/A
