Air Flow functionality
(Available using TSI’s Air Probe on QUESTempº 36 model.)
Air flow is measured in meters per second over a range of 0 to 20 m/s in 0.1 m/s increments. The
sensor should be placed or held perpendicular in the air stream. Unlike many anemometers, the
omni-directional sensor does not require rotating to find the maximum reading. Be careful not to
block the air flow with your body during measurements. The sensor’s measuring tip is fragile; be
cautious if measuring in ducts.
The Air Probe may be either hand held or mounted behind the QUESTemp 36 using the
mounting bracket hooked to the sensor bar beneath the center bulb sensor. (See Figure 1-21
below.)
A green lamp indicator in the Air Probe indicates that it is turned on and the battery is good. If the
green indicator turns off while the switch is in the On position, replace or recharge the battery.
To connect, follow steps 1-3 below.
Figure 1-21: Air flow configuration
1. Clip front of bracket around lip of
sensor bar.
2. Tighten bracket to sensor bar with
thumb screw.
3. Attach air probe to bracket
with thumb screen
