Status Descriptions
Menu item
Description
Possible values
Description
1.
Mode
Current configured mode of a unit
Standalone
Unit is in Standalone mode
Primary
Unit is the designated Primary in a redundant pair
Backup
Unit is the designated Backup in a redundant pair
2.
Unit
The unit’s status
Booting
Unit is booting its operating system
Starting
Unit is starting its application
Config Error
There is an issue with the configuration
Interface Fault
There is an internal device issue
Running
Unit is working correctly
Running (Activating)
Unit is working and activating to be the Active redundant
unit
Running
(Deactivating)
Unit is working and deactivating from being the Active
redundant unit
REMOTELY
SHUTDOWN
Unit has been remotely shutdown by its redundant partner
3.
Power
Current power status of the unit’s
power supplies
OK
Power supplies are functioning correctly
Fault
There is a fault with one of the power supplies
4.
Redundancy
Status of the redundancy system
Enabled
Units are set up as a redundant system and is enabled
Not Setup
Not running a configuration with redundancy system
defined
Error
Configuration error/no comms
Unavailable
Redundancy setup but cannot communicate to paired
device
No Primary
There is no Primary available within paired units (via Direct
Link Cable)
No Backup
There is no Backup available within paired units (via Direct
Link Cable)
5.
Local Inputs:
Outputs:
Relays
Status of unit’s GPIO and Relays
Inputs
Input Off Input On
Outputs
Output Off Output On
Relays
Relay Off Relay On
6.
Status
Unit’s current redundancy status
Active
Unit is currently the Active controller in redundant pair
Standby
Unit is currently in Standby ready to become the Active
controller in the redundant pair
Activating
Unit is becoming the Active unit in the redundant pair
Deactivating
Unit was the Active controller and is deactivating
Error
There is an error with the unit’s status in the redundant pair
7.
Failover
The failover mode of the
redundant pair (both units should
reflect the same status)
Auto (Armed)
System is in Auto and ‘Armed’ ready to failover in the
occurrence of a failover event
Auto (Triggered)
System is in Auto but has already failover over
Auto (Unavailable)
System is in Auto however there is a problem with one of
the units in the redundant pair
Manual
The system is in Manual and can be manually failed over,
the system will not automatically failover in this mode
Unavailable
There is an issue with the system and failover is unavailable
8.
Backup Link
Link between Primary and Backup
units for redundancy
communications
Direct Link (Green =
Ok)
Status of communication to paired unit via the dedicated
Direct Link Cable
IP Link
(Green = Ok)
Status of communication to paired unit via IP connection
(only via NIC 1)
