THE CONVECTION CIRCUIT
101
102
100
99
98
97
105
103
1
1
104
2
106
NOTICE:
This device complies with Part 18
of the FCC Rules.
Operation is subject to the followi
ng conditions:
1. This device may not cause harmful
interference.
WARNING:
DHHS Federal Performance Standard 2
1 CFR 1030.10.
To provide contin
ued protection aga
inst electrical
Pour assurer protection continue c
ontre le choc
shock, connect to
properly grounded outlets only.
AVERTISSEMENT
:
correctement mise
a terre.
electrique branchez seulement a une
prise
undesired operati
on.
2. This device mus
t accept any int
erference
received, includi
ng interference t
hat may cause
This Oven complies
with applicable sec
tions of
CONVECTION CIRCUIT PARTS
F
igure 32
97. 101688 Screw, #8 x 1/2” PTH
98. NGC-1081 Cover, Motor, Cap
99. 100905 Nut, 1/4”-20, Flange
100. NGC-1025
Assy
, B
lo
w
er M
otor
101. 101688 Screw, #8 x 1/2” PTH
102. 100661 Heater, Convection
103. 100443
Contr
oller, Motor
104. 101284 Relay, K4/K5 SSR
105. 100592 Buss, Fuses (12 Amp)
106.
102075
High-Limit Thermostat
Assembly Notes
1. Cut insulation covering Conversion Heater
as sho
wn.
2. Gasket Convection Heater (P/N NGC-1043)
not sho
wn for clarity
.
: Convection Circuit Assembly and Parts
To Next Page
