TurboChef NGC (Tornado) User Manual

129
107
117
2X
AR
109
108
4X
AR
117
124
110
126
4X
128
127
111
122
4X
114
125
116
119
118
121
120
117
123
4X
AR
115
122
113
112
2X
1
SIDE VIEW
.20
BLOWER MOTOR PARTS
Figure 33
107.
700-0306-2
H
ub
, Small
108. NGC-1019-2 Fan Blade, NGC Oven
109.
NGC-1020 Ring, Fan Blade
110. NGC-1021 Plate, Blower Cap
111. 700-0284 Shim, Seal
112. NGC-1024 Sealing Block Blower
113. 100443 Washer, Wave Spring, 30mmOD
114. NGC-1023 Clamp, Blower Seal
115. 102708 Heat Slinger, Fan, PM Motor
116.
100882
M
otor, 1HP, Flange Mount
Aspen
117. 100790 Loctite, #272
118. NGC-1022 Spacer, Blower Motor
119. 101394 Bolt, Hex, 1/4”-20 x 3/4” Lg,
CRES
120. 101394
W
asher
, S
plitlock, 1/4”, CRES
121. 101392 Screw, PFLH, 1/4”-20 x 1/2” Lg,
100
º
, Cres
122. 102963 Nut, Hex, #10-32 Ext Tooth
K
eps, CRES
123. 102200 Washer, Flat, 1/4”, Cres
124.
102921
Screw, #8-32 x 3/8” Int Tooth
K
eps, CRES
125. 100730 Key, Woodruff, Steal
126. NGC-1122 Spacer, Blower, Insulation
127.
NGC-1102
H
eat S
hield, B
lo
w
er M
otor
128. NGC-1123 Insulation, Blower Plate
129. 101711 Set Screw, Skt Hd
#10-32 x 5/16” CRES
As
sembly Notes
1. Item 115 to be located and installed as shown
on shaft shoulder near the motor housing.
2. Spacing between Item 108 and 110 must be
0.20 inches minimum. S
ee side vie
w
.
43
 : Blower Motor Assembly and Parts
THE CONVECTION CIRCUIT
