TurboChef NGC (Tornado)

54
SERVICE PARTS AND ILLUSTRATIONS
FIGURE 16: MICRO
WAVE SYSTEM PARTS
Chapter 5: The Microwave System - Page 23
(ORG)
30
34
(BLK)
31
32
33
FFA
COOLING
FANS
FILAMENT AND
HIGH VOL
TAGE
TERMINALS
Microwave System Parts
30. 100861 Magnetron
31. 102070 Mag Thermostat
32. NGC-1163 Ad, Insulator
33. 100186 Screw #6 Sheet Metal
34. 100186 Magnetron Wire
35
37
36
43
42
39
40
41
38
Wave Guide/Wave Guide Cover Parts
35. NGC-1097 Assy, Wave Guide Cover
36. 102921 Scr
e
ws,
#8-32 x 3/8”, SS
37. 101688
Screws,
#8 x 1/2” S
heet M
etal
PTH
38. NGC-1047 Support, Frame
39. 102809 Screws, #8-32 x 3/8” CSK (100
º
)
40. NGC-1106
Assy, Wave Guide #2
41.
100861
M
agnetr
on
#2
42. 100861
Magnetron #1
43.
NGC-1044
Assy
,
Wave Guide
#1
FIGURE 17: WAVE GUIDE COVER/WAVE GUIDE REMOVAL AND REPLACEMENT
Chapter 5: The Microwave System - Page 25
