Pressure Sensors Series PS…
3 Description of pressure sensors, PS series
The devices of the PS series… are intelligent pressure sensors which have been
developed especially for the use in machine engineering.
The following 3 output variants are available:
■
…2UPN8X 2 switching outputs (pnp/npn)
■
…LI2UPN8X 1 output switching (pnp/npn) and 1 output
switching (pnp/npn) or analog output (current)
■
…LUUPN8X 1 output switching (pnp/npn) and 1 analog output
(voltage)
The measured pressure can be displayed in bar, psi, kPa, MPa and 10 different
selectable pressure units (Ud1-Ud10). The housing PS…-5… can be rotated
(360°) and fixed after mounting.
Relative pressure
Type Measuring [bar] Admissible rel. press. [bar]
PS01VR-… -1…0 3
PS001R-… 0…1 3
PS001V-… -1…1 3
PS003V-… -1…2.5 7
PS010V-… -1…10 25
PS016V-… -1…16 40
PS025V-… -1…25 65
PS040V-… -1…40 100
PS100R-… 0…100 250
PS250R-… 0…250 625
PS400R-… 0…400 900
PS600R-… 0…600 900
Absolute pressure
Type Measuring [bar] Admissible rel. press. [bar]
PS001A-… 0…1 3
PS003A-… 0…2.5 7
PS010A-… 0…10 25
PS016A-… 0…16 40
PS025A-… 0…25 65
