Pressure Sensors Series PS…
Pressure Sensors Series PS
8.2 Displayable units (Uni)
For pressure sensors, only displayable units are indicated. Which units can be
displayed depends on the upper limit of the measuring range. The following
table shows the supported measuring units:
Display LED Unit Display LED Unit
bar bar bar Ud4 misc inH
2
O (39°F)
Psi Psi Psi Ud5 misc ftH
2
O (39°F)
kPa kPa kPa Ud6 misc inHg (60°F)
MPa MPa MPa Ud7 misc inHg (32°F)
Ud1 misc Millibar/Hektopascal Ud8 misc mH
2
O (16°C)
Ud2 misc mmHg (0°)/Torr Ud9 misc mH
2
O (4°C)
Ud3 misc inH
2
O (68°F) Ud10 misc Kg/cm
2
Meas. range bar psi kPa Mpa Ud1 Ud2
Ud3
1 bar + + + + + + +
3 bar + + + + + + +
10 bar + + + + – + +
16 bar + + + + – – +
25 bar + + + + – – –
40 bar + + + + – – –
100 bar + + – + – – –
250 bar + + – + – – –
400 bar + + – + – – –
600 bar + + – + – – –
Meas. range bar psi kPa Mpa Ud1 Ud2
Ud3
1 bar + + + + + + +
3 bar + + + + + + +
10 bar + + + + + + +
16 bar + + + + + + +
25 bar – + + + + + +
40 bar – + + + + + +
100 bar – + + + + + +
250 bar – + + + + + +
400 bar – – – – + + +
600 bar – – – – + + +
